9 year old Labrador Retriever

August 25, 2016 By Allison Zwingenberger

Today’s case is a 9-year-old male neutered Labrador Retriever with two-day history of cough. What are your radiographic findings?

R LAT Thorax
L LAT Thorax
DV Thorax
DV Thorax

Show findings...

Findings

The cardiac silhouette is moderately enlarged with left atrial enlargement causing dorsal and lateral displacement of the principal bronchi. There is a broad based soft tissue opacity bulge effacing the cranial cardiac silhouette which appears to be confluent with the heart. There is a bulge in the left cardiac silhouette in the position of the left auricle. The pulmonary parenchyma is normal. No other abnormalities are noted.

Show differential diagnosis…

Differential Diagnosis

The larger opacity dorsal to the heart is likely due to herniation of the right atrium through the pericardium. The left auricular bulge and left atrial enlargement are likely secondary to valvular insufficiency. There is no evidence of heart failure at this time.

Show diagnosis…

Diagnosis

  • Right auricular herniation
  • Right atrium was confirmed on echocardiography with bubble study
  • Severe mitrial and tricuspid regurgitation causing atrial and auricular enlargement

Filed Under: Canine, Case of the Day, Radiographs, Thorax
